The EMRAX 348 Electric Motor
| |
| EMRAX 348 Technical Data Summary |
| Mechanical |
Electrical |
| Type: |
Axial flux synchronous permanent magnet motor/generator; sinusoidal three phase |
Maximal battery voltage: |
800 (HV) / 800 (MV) / 340 (130) (LV) Vdc |
| Casing diameter: |
348 mm |
Peak power
(at 4000 RPM): |
300 kW |
| Axial length: |
107 mm |
Continuous power*: |
up to 150 kW |
| Dry mass: |
39 kg (AC) / 40 kg (CC, LC) |
Peak torque: |
1000 Nm |
| Stator cooling: |
air (IP21) / water glycol (IP65) / combined (IP21) |
Continuous torque*: |
up to 500 Nm |
| Mounting: |
Front: 6x M10 threaded holes
Back: 10x M8 threaded holes |
Efficiency: |
up to 98% |
* Depends on the rotation speed and thermal conditions. |
|
| |
|
|
|
