Specifications
P9
Performance
-Satellite : GPS L1 ,GLONASS L1,BeiDou 2rd generation
B1 Channel : 72
-Positioning accuracy : Horizontal 2 mCEP
-Updating speed : 1Hz (highest10Hz)
Data output;NMEA-0183
-Real-time correction : RTCM 2.x, 3.x
Physical parameter
-Operation system : Windows Mobile 6.5
-Processor : TI Sitara AM335x 1GHz
-RAM : 512MB
-ROM : 4G board flash memory (32Goption)
-Screen : 3.7inch Blanview TFT transflective screen,480×640VGAresolution ratio
-Battery : 25.16W big capacity battery, single battery endurance>10hours
Communication : Bluetooth, Version2.1+EDR,
-USB OTG (directly conenct Uflash disk)
Camera : 5millionpixel automati focusing
WIFI : WLAN 802.11b/g
-Pressbutton : All digital alphabetmulti-functionkepboard,F1-F4definable shortcusts,lateral definable collect keys
-Size : Length192.0mm,Width93.5mm, thickness43.0mm
-Weight : 925g (with battery)
Environment
Protection level:IP67
Temperature:Opration temperature-20°C-+60°C,
Storage temperature:-30°C-+70°C
Humidity:5%-95%Rhnon-condensing
Drop :1.2meters fell on the cement plywood ground without damage



.
