Potentiometric & Analog Linear Transducers



LT - Potentiometric Measuring
• Absolute measurement of displacement
• Small size
• Potentiometric measuring
• Resolution 0,01mm
• Very Long Life : 100 million movements



LTM - Potentiometric Measuring
• Absolute measurement of displacement
• Potentiometric measuring
• Resolution 0,01mm
• Very Long Life : 100 million movements
• Excellent Linearity %0,3

LTP - Potentiometric Measuring

• Absolute measurement of displacement
• Twin bearing actuating rod
• Mountable over backlash free pivots heads
• Potentiometric measuring
• Resolution 0,01mm
• Very Long Life : 100 million movements
• Excellent Linearity %0,3

LTC - Potentiometric Measuring
• Absolute measurement of displacement
• Square body (rod diameter 6mm)
• Twin bearing actuating rod
• Mountable over backlash free pivots heads
• Potentiometric measuring
• Resolution 0,01mm
• Very Long Life : 100 million movements
• Excellent Linearity %0,3

Magnetic Linear Encoders&Sensors

MLS 130 - ULTRA SMALL SIZE
With Use : B Series Magnetic Tape
PS 110 Profile Systems
PS 200 Series Profile Systems
• Very small measuring head (metal enclosure)
• Wide range of available resolution up to 1 µm
• Protection class IP67
• Resistant to humidity
• Robust shielded aluminum
• Incremental outputs A, /A, B, /B and Z Reference signal
• Output signal Push-pull, TTL or RS422 line driver
• 5VDC or 10...30VDC Power Supply

MLS 110 - WITH CABLE GLAND
With Use : B5 Magnetic Tape
PS110 Profile Systems
PS200 Series Profile Systems
• Very small measuring head (metal enclosure)
• Wide range of available resolution up to 1 µm
• Protection class IP67
• Resistant to humidity
• Incremental outputs A, /A, B, /B and Z Reference signal
• Output signal Push-pull, TTL or RS422 line driver
• 5VDC or 10...30VDC Power Supply

MLS 110 - WITH SPIRAL GLAND
With Use : B5 Magnetic Tape
PS110 Profile Systems
PS200 Series Profile Systems
• Very small measuring head (metal enclosure)
• Wide range of available resolution up to 1 µm
• Protection class IP67
• Resistant to humidity
• Robust shielded aluminum
• Incremental outputs A, /A, B, /B and Z Reference signal
• Output signal Push-pull, TTL or RS422 line driver
• 5VDC or 10...30VDC Power Supply

MLS 120 - SLIDER INTEGRATED BODY
With Use : B5 Magnetic Tape
PS110 Profile Systems
PS200 Series Profile Systems
• Very small measuring head (metal enclosure)
• Socket System Sensor
• Slider Integrated Body
• Wide range of available resolution up to 1 µm
• Protection class IP67
• Resistant to humidity
• Robust shielded aluminum
• Incremental outputs A, /A, B, /B and Z Reference signal
• Output signal Push-pull, TTL or RS422 line driver
• 5VDC or 10...30VDC Power Supply
MLS 210 - WITH SPIRAL GLAND
With Use : PS310 Profile Systems
• Metal enclosure
• Protection class IP67
• Resistant to humidity
• Robust shielded aluminum
• Incremental outputs A, /A, B, /B and Z Reference signal
• 5VDC or 10...30VDC Power Supply
• Output signal Push-pull, TTL or RS422 line driver
MLS 210 - WITH SPIRAL GLAND and SLIDER JOINTS
With Use : PS110 Profile Systems
• Metal enclosure
• Twin Sliders
• Protection class IP67
• Resistant to humidity
• Robust shielded aluminum
• Incremental outputs A, /A, B, /B and Z Reference signal
• 5VDC or 10...30VDC Power Supply
• Output signal Push-pull, TTL or RS422 line driver

B5 Magnetic Tape - Pole Length : 5 mm
With Use : MLS110 Reader Head Sensor
MLS120 Reader Head Sensor
MLS210 Reader Head Sensor
• Easy mounting by glueing
• 5 mm pole length
• High accuracy
Standart ±40 µm/m optional ±20 µm/m
• Protection class IP67
• Resistant to humidity
• Stainless steel cover strip (Upside and Downside)
• Up to 100 m available
• Nitrile Rubber


B2 Magnetic Tape - Pole Length : 2 mm
With Use : MLS110 Reader Head Sensor
MLS120 Reader Head Sensor
MLS210 Reader Head Sensor
• Easy mounting by glueing
• 2 mm pole length
• High accuracy
Standart ±40 µm/m optional ±20 µm/m
• Protection class IP67
• Resistant to humidity
• Stainless steel cover strip (Upside and Downside)
• Up to 100 m available
• Nitrile Rubber
