Compact, powerful, yet quiet

The WPLN series gearhead is the enhanced right angle high precision planetary gearhead for applications with very high precision, requiring a right angle configuration. The design of this unit features a hypoid right angle stage design (up to 10:1 ratio) and in higher ratios, an integration of the hypoid stage with high output torque planetary stage. As a result of the optimized, precision hardened and lapped hypoid gears, the noise generation is exceptionally low.

  • Low backlash <5arcmin
  • High output torque - the industry's highest torque density
  • Small installation space
  • Precise, easy, and flexible motor mounting (PCS-2 system)
  • Balanced motor pinion
  • High efficiency (up to 96%)
  • Ground and honed gearing
  • 11 ratios 4:1 to 100:1
  • Low noise (<66 dB(A))
  • Consistent quality (ISO 9001 and 14001)
  • Operable in any mounting positions
  • Lifetime lubrication
  • Numerous options
  • Balanced motor connection
