| Body: |
Aluminium. |
| Shaft: |
Stainless Steel. |
| Bearings: |
Ballraces. |
| Bearings life: |
1x1010 rev. |
| Absolute maximum speed: |
6000 rpm. |
| Protection class attending DIN 40050: |
IP65. |
| Moment of inertia: |
30 gcm2. |
| Torque 20ºC (68ºF): |
2,0 Ncm. |
| Absolut maximum axial shaft load: |
40 N. |
| Absolutmaximum radial shaft load: |
60 N. |
| Weight: |
0,5 Kg. |
| Operating temperature range: |
-20ºC a +60ºC. |
| Storage temperature range: |
-20ºC a +70ºC. |
| Vibration proof: |
100 m/s2. |
| Shock resistance: |
300 m/s2. |
| Atmospheric humidity: |
98% without condensation. |
| Frequency: |
Depend on electrical output. |
| Test before deliver: |
48 hours. |
| Maximum increments per turn: |
Up to 10.000. |
| Axial or radial connection: |
2 meters cable or industrial connector.
(Other cable length on request) |
