: : : : : : : : : :Halogen Light Source : : : : : : : : : :

  50W Series
     MHF-V501

Halogen Light Source
       Compact and multifunctional 50W Halogen light source at an excellent cost and great performance. This uits costs the least and lasts the longest of all our Halogen light sources.
  • Compact, lightweight, and reasonable
  • With various security functions
  • Environment-friendly model
  • external analog control standard, other control options available
Special power source specifications
Order Code
MHF-V501 MHF-501-SC MHF-V501-D *MHF-V501-D50 *MHF-V501-DSC
Remarks
Built-in shutter
(Normally open)
Built-in shutter
(Normally closed))
With external 8-bit digital dimmer
With extermal digital dimmer adn built-in shutter
(Normally open)

With extermal digital dimmer and built-in shutter

(Normally closed)
Commodity code A-0414 A-0413 A-0503 A-0503 A-0502
Optional Parts
Cable with external remote connector MC=EXC-02
External remote connector D-SUB155
Replacement lamp LM-50
MHF-V501

 *1 Only compatible lamps can be used.

     *2Man lamps are lit and the time measurements until their filaments blow are normally distributed. The average time from the peak time until the survival ration of 50% is called the average life.

     *3 The average illuminance is at 50 mm from the fiber end at the maximum volume when Moriex standard light huide (MSG4-2200S) is attached.
