Basler runner Series
Cost-effective GigE Vision Line Scan Series
The Basler runner Series – 7 New Models With Basler's Famous Image Quality

Your benefits from the Basler runner series include:
 |
1k, 2k mono CCD |
 |
2k color tri-linear CCD |
 |
GigE Vision compliant interface |
 |
Inexpensive cabling and screw lock connectors |
 |
Up to 100 meter cable lengths for more flexibility |
 |
Save cost - no frame grabber required |
Specification |
ruL1024-19gm |
ruL1024-36gm |
ruL1024-57gm |
ruL2048-10gm |
Sensor Size |
1024 pixels |
1024 pixels |
1024 pixels |
2048 pixels |
Sensor Type |
Thompson TH7813A Linear monochrome CCD |
Thompson TH7813A Linear monochrome CCD |
Thompson TH7813A Linear monochrome CCD |
Thompson TH7814A Linear monochrome CCD |
Pixel Size |
10 µm x 10 µm |
10 µm x 10 µm |
10 µm x 10 µm |
10 µm x 10 µm |
Max Line Rate |
18.7 kHz |
35.7 kHz |
56.1 kHz |
9.5 kHz |
Video Output Type |
GigE Vision |
GigE Vision |
GigE Vision |
GigE Vision |
Pixel Depths |
Selectable 8 bit or 12 bit |
Selectable 8 bit or 12 bit |
Selectable 8 bit or 12 bit |
Selectable 8 bit or 12 bit |
Video Output Format |
Mono8, Mono12, Mono12 Packed |
Mono8, Mono12, Mono12 Packed |
Mono8, Mono12, Mono12 Packed |
Mono8, Mono12, Mono12 Packed |
Synchronization |
Via external signal or software |
Via external signal or software |
Via external signal or software |
Via external signal or software |
Exposure Control |
Trigger width, time, or off |
Trigger width, time, or off |
Trigger width, time, or off |
Trigger width, time, or off |
Power Requirements |
12 VDC (+/- 10%) 6.0 W |
12 VDC (+/- 10%) 7.0 W |
12 VDC (+/- 10%) 8.0 W |
12 VDC (+/- 10%) 6.5 W |
Inputs/Outputs |
3 in / 2 out or direct encoder input |
3 in / 2 out or direct encoder input |
3 in / 2 out or direct encoder input |
3 in / 2 out or direct encoder input |
Lens Mount |
C or F-mount |
C or F-mount |
C or F-mount |
C or F-mount |
Housing Size (L x W x H in mm) |
54.5 x 62.0 x 62.0 |
54.5 x 62.0 x 62.0 |
54.5 x 62.0 x 62.0 |
54.5 x 62.0 x 62.0 |
Weight (without lens adapter) |
Max. 285 g |
Max. 285 g |
Max. 285 g |
Max. 285 g |
Conformity |
CE, FCC, GenICam, GigE Vision |
CE, FCC, GenICam, GigE Vision |
CE, FCC, GenICam, GigE Vision |
CE, FCC, GenICam, GigE Vision |
Specification |
ruL2048-19gm |
ruL2048-30gm |
ruL2098-10gc |
Sensor Size |
2048 pixels |
2048 pixels |
2098 pixels per line |
Sensor Type |
Thompson TH7814A Linear monochrome CCD |
Thompson TH7814A Linear monochrome CCD |
Kodak KLI-2113<br>tri-linear color CCD |
Pixel Size |
10 µm x 10 µm |
10 µm x 10 µm |
14.0 µm x 14.0 µm |
Max Line Rate |
18.7 kHz |
29.2 kHz |
9.2 kHz |
Video Output Type |
GigE Vision |
GigE Vision |
GigE Vision |
Pixel Depths |
Selectable 8 bit or 12 bit |
Selectable 8 bit or 12 bit |
Selectable 8 bit or 12 bit |
Video Output Format |
Mono8, Mono12, Mono12 Packed |
Mono8, Mono12, Mono12 Packed |
RGB 8, RGB 12, YUV 4:2:2 |
Synchronization |
Via external signal or software |
Via external signal or software |
Via external signal or software |
Exposure Control |
Trigger width, time, or off |
Trigger width, time, or off |
Trigger width, time, or off |
Power Requirements |
12 VDC (+/- 10%) 7.5 W |
12 VDC (+/- 10%) 8.5 W |
12 VDC (+/- 10%) 5.1 W |
Inputs/Outputs |
3 in / 2 out or direct encoder input |
3 in / 2 out or direct encoder input |
3 in / 2 out<br>or direct encoder input |
Lens Mount |
C or F-mount |
C or F-mount |
F or V-mount |
Housing Size (L x W x H in mm) |
54.5 x 62.0 x 62.0 |
54.5 x 62.0 x 62.0 |
54.5 x 62.0 x 62.0 |
Weight (without lens adapter) |
Max. 285 g |
Max. 285 g |
Max. 285 g |
Conformity |
CE, FCC, GenICam, GigE Vision |
CE, FCC, GenICam, GigE Vision |
CE, FCC, GenICam, GigE Vision |
|
