Low noise CCD camera, Peltier cooling, up to 11 MP

The Bigeye is a low noise CCD camera. It satisfies even the highest expectations for excellent image quality. The peltier cooling provides a superior signal-to-noise ratio even with very long exposure times.
Bigeye NIR camera versions are designed for applications which require sensitivity both in the visible spectrum and the NIR spectrum.

  • Sensitive Sony and Kodak sensors, up to 11 Megapixels
  • Peltier cooling for long exposure times
  • Superior signal/noise ratio
  • Robust metal housing for industrial use
  • GigE Vision, also available with Camera Link

Specification

Bigeye P-132 P-132 NI P-62 P-629 NI
Interface IEEE 802.3 1000baseT
Resolution 1280 x 1024 1280 x 1024 3072 x 2048 3072 x 2048
Sensor Sony ICX285 Sony ICX285 Kodak KAF-6303E Kodak KAF-6303E
Sensor type CCD Progressive
Sensor size Type 2/3 Type 2/3 Type 35 mm Type 35 mm
Cell size 6.45 µm 6.45 µm 9.0 x 9.0 µm 9.0 x 9.0 µm
Lens mount C-Mount C-Mount F-Mount F-Mount
Max frame rate at full resolution 12.5 fps 12,5 fps 0,67 fps 0,67 fps
A/D 14 bit
Output
Bit depth 12 bit 12 bit 14 bit 14 bit
Mono modes Mono8, Mono10, Mono12 Mono8, Mono10, Mono12 Mono8, Mono10, Mono12, Mono14, Mono16 Mono8, Mono10, Mono12, Mono14, Mono16
Raw modes Cool: BayerGB8, BayerGB10, BayerGB12 BayerGB8, BayerGB10, BayerGB12
Operating conditions/Dimensions
Operating temperature 0 °C ... 35 °C
Power requirements (DC) 12 V
Power consumption (12 V) 33.6 W
Mass 1340 g (Cool) 1410 g 1460 g 1460 g
Body Dimensions
(L x W x H in mm)		 111 x 90 x 99 incl. connectors, w/o lens 111 x 90 x 99 incl. connectors, w/o lens 141.75 x 90 x 109 incl. connectors, w/o lens 141.75 x 90 x 109 incl. connectors, w/o lens
Regulations CE, RoHS (2002/95/EC)



Bigeye P-1100
Interface IEEE 802.3 1000baseT
Resolution 4024 x 2680
Sensor Kodak KAI-11002
Sensor type CCD Progressive
Sensor size Type 35 mm
Cell size 9 µm
Lens mount F-Mount
Max frame rate at full resolution 1.6 fps
A/D 14 bit
Output
Bit depth 12 bit
Operating conditions/Dimensions
Operating temperature 0 °C ... 40 °C
Power requirements (DC) 12 V
Power consumption (12 V) 36 W
Mass 1390 g
Body Dimensions
(L x W x H in mm)		 143 x 90 x 99 incl. connectors, w/o lens
Regulations CE, RoHS (2002/95/EC)
